PTFE165-1550
PTFE-coated fiberglass cloth, also known as Teflon-coated fiberglass, is a versatile material combining the strength of fiberglass with the properties of PTFE (polytetrafluoroethylene, also known as Teflon). It is characterized by high heat resistance, low friction, electrical insulation, and chemical resistance. These features make it suitable for a wide range of applications, including industrial belting, heat sealing, insulation, welding blanket, thermal jacket, insulation mat, fireproof door and curtain and architectural membranes.
PTFE coated fiberglass fabric withstands high temperature up to 260C°(500°F), smooth surface offers quick release and low friction coefficient, coated with fiberglass cloth basic layer has strong tensile for versatile applications.
Model No.: | PTEF-165-1550 | Weave Type | Plain woven |
Glass grade | E-glass | Alkali | Free |
Density(g/m²) | 165-1550 | Thickness | 0.08-0.9mm |
Width | 2-125cm or custom | Length/Roll | 50m or custom |
Bobbin diameter | 58mm/76mm/83mm | Roll Diameter | 350-600mm |
MOQ/order | 10 Rolls | Temp Resistant | -140C°-260° |
Heat resistance: PTFE-coated fiberglass can withstand high temperatures, making it ideal for applications like heat sealing and industrial belting in high-temperature processes.
Low Friction: The low coefficient of friction of PTFE provides excellent release properties and reduces wear and tear in moving parts.
Electrical Insulation: PTFE is a good insulator, and the fabric offers excellent electrical insulation properties.
Chemical Resistance: PTFE is highly resistant to chemicals, making the fabric suitable for use in chemical processing and containment.
Durability: The combination of fiberglass and PTFE results in a durable material that can withstand harsh conditions and resist mechanical damage.
UV and Weather Resistance: PTFE-coated fiberglass is resistant to UV radiation and weathering, making it suitable for outdoor applications.
Moisture Resistance: The material is impervious to water and moisture, ensuring long-term performance in humid environments.
Non-Stick Properties: PTFE's non-stick surface is crucial in applications like heat sealing and release liners, preventing materials from adhering to the fabric.
Flexibility: The fabric can be flexible, allowing it to conform to different shapes and surfaces.
Anti-Static Properties: Some PTFE-coated fiberglass fabrics are designed with anti-static properties, which can be useful in preventing static electricity buildup in certain applications.
Uses for industrial belting, heat sealing, release liners, thermal insulation, chemical processing, architecture membranes, baking sheet, conveyor belt, pan liners in food industry, aerospace, electrical insulation, medical applications, automotive and so on.
1. If made in Alkali-Free E-glass fiberglass filament?
Yes, Alkali-Free
2. If Free Sample can be supported?
Yes, free sample can supply you for testing.
3. If tape can be customized?
Yes, we offer design-based customization, also sample-based customization services.
4. What’s the delivery time for bulk orders
15-20 working days after order confirmed
5. Warranty period
2 year after goods was on board
